RRFID BASIC C M G 1 | RFID safety switch, actuator coded, 1m cable

Welke lengte heeft u nodig?
/
U heeft 0 stuks nodig voor 0 euro incl. BTW
RRFID BASIC C M G 1
£ 92,50
Ask for quotationAdd to wish list
 Delivery time: approx. 4 weeks
Add to favorites
  • Product description and specifications
  • Documents
  • Accessories
  • Ask a Question

Barcode

Product description

The ReeR Safety R-SAFE RFID safety switches provide optimal safety in industrial environments through the use of RFID technology. These switches can connect up to 16 RFID sensors (Pro and Plus versions only) in series, enabling an efficient and cost-effective installation by reducing the need for separate cabling from each sensor. The switches are fully mechanically compatible with other ReeR Safety safety sensors, such as the Magnus RFID and Magnus MG "S" series, and can be seamlessly integrated with the Mosaic safety PLCs. The RFID safety switches are available with a standard actuator and a more compact Slim actuator.

Available in 3 versions
The RFID safety switch series is available in three different versions:
  • Basic: The Basic version features an automatic restart, series connection not possible
  • Pro: The Pro version features an automatic restart and allows series connection (max. 16) with individual sensor status
  • Plus: The Plus version features both manual and automatic restart and allows series connection (max. 16) with individual sensor status
Flexible application possibilities
Three different coding typesindividually coded, uniquely coded, and actuator codedoffer flexible application options. ReeR Safety has implemented special measures against tampering, such as screw covers and unique coding. The R-SAFE RFID safety switches comply with the highest safety standards SIL 3 - SILCL 3 and PL e - Cat. 4 and are suitable for various industries, including food & beverage, packaging, pharmaceuticals, printing, paper, logistics, chemical industry, and injection moulding.

Key features of the R-SAFE RFID contactless switches:
  • RFID technology enhances safety by communicating with authorised actuators
  • Available with standard (28.5 x 42 x 18mm) and Slim (9 x 52 x 18mm) actuator
  • Connect up to 16 RFID sensors in series for efficient installations (Pro and Plus versions only)
  • Complies with the highest safety standards: SIL 3, SILCL 3, PL e, Cat. 4
  • Suitable for various industries
  • Protected against tampering with covered screws and unique coding
  • User-friendly with multi-status LED and diagnostic output

Documents

Specifications

CodingActuator coded
PrincipleRFID
Switching distance12 mm
HousingPlastic
TypeSensor + Slim actuator
Output2 OSSD
1 diagnose
Connecting typeCable 1 m
HousingCube
SeriesR-Safe RFID
Protection standardIP 65
IP 67
IP 69K
CertificationsCE
UKCA
ECOLAB
TÜV
SIL 3
BrandReer
CategoryNon contact safety switches
Product codeRR004046
Supplier code1294100
Unitst

Accessories

Mosaic M1 | PLC central module
 Stock: 57 piece(s)
£ 345,00
Product code: RR401896
Mosaic M1S | PLC central module
£ 380,00
Product code: RR401382
Mosaic M1S COM | PLC central module
 Stock: 127 piece(s)
£ 580,00
Product code: RR403866
